Protect your photovoltaic inverter against lightning. ALMA SOLAR, the leader in sales solar panels on the internet offers electrical boxes dedicated to photovoltaic installations. The norms in effect today requires you to protect yourself against natural elements. Order to answer this need, we have a wide range of electric box for photovoltaics....
Protect your photovoltaic inverter against lightning. ALMA SOLAR, the leader in sales solar panels on the internet offers electrical boxes dedicated to photovoltaic installations. The norms in effect today requires you to protect yourself against natural elements. Order to answer this need, we have a wide range of electric box for photovoltaics. DC cabinets are equipped with MC4 connectors to facilitate the connection of your solar panels. Furthermore, to protect against lightning, you will find a surge arrester type 2 (dedicated to photovoltaics). The AC boxes are equipped with inter-differential delayed action. Indeed, it is important to delay the trigger because the current defects can be caused by the network and not a real danger. All our boxes are equipped sized isolator for voltages and current. We verify, when ordering, compliance of cabinet and we assure certification in force. Order safely your electrical protection.
Electrical box (alternative current) for photovoltaic protection. Cabinet including wiring diagram. Required for each photovoltaic system. AC box 230 V AC single-phase up to 4 kW with differential circuit breaker 16 A - 30 mA + surge arrester type A.
Electrical box (alternative current) for photovoltaic protection. Cabinet includes the wiring diagram. Required for each photovoltaic system. AC box 230 V AC single-phase up to 6 kW with differential circuit breaker 32 A - 30 mA + surge arrester type A.
Electrical box for photovoltaic protection. DC box includes wiring diagram. Required for every photovoltaic system. DC box under 600 V DC, 1 string, switch 25 A, lightning, MC4
Electrical box for photovoltaic protection. Cabinet including wiring diagram. Required for each photovoltaic system. DC box under 1,000 V DC, 1 string, switch 25 A, lightning, MC4
Protection box for batteries at 30A, 500 V DC.
Electrical box (alternative current) for photovoltaic protection. Cabinet includes the wiring diagram. Required for each photovoltaic system. AC box 230 V AC single-phase up to 10 kW with differential circuit breaker 50A - 30 mA + surge arrester type A.
This single-phase Solax box allows the AC GRID output and the EPS output to be connected to the same injection point. This box works with Solax Hybrid SK-SU and Solax Hybrid X1-D-E inverters. The Solax Hybrid AC GRID output works with the power grid. The EPS output operates in the absence of electrical network, i.e. during a blackout. You have 2 inputs...
Electrical box (continuous current) for photovoltaic protection. Cabinet includes wiring diagram. Required for each photovoltaic system. This DC box is needed for inverters with 2 independant entrances (2x MPPT). DC box 2 x MPPT - DC breaker 25 A - 1000V, surge protector type 2, 1 string / MPPT - connexion with MC4.
This Solax box allows the AC GRID output and the EPS output to be connected to the same injection point. This box works with Solax Hybrid X3-D-E inverters. The Solax Hybrid AC GRID output works with the power grid. The EPS output operates in the absence of electrical network, i.e. during a blackout. You have 2 inputs for 2 Solax outputs and 1 output for a...
Electrical box (alternative current 3-phase) for photovoltaic protection. Cabinet includes the wiring diagram. Required for each photovoltaic system. AC box 400 V AC 3-phase AC up to 10 kW with differential circuit breaker 16 A - 30 mA + surge arrester type A.
Electrical box (alternative current, triphase) for photovoltaic protection. Cabinet includes the wiring diagram. Required for each photovoltaic system. AC box 400 V AC 3-phase AC up to 20 kW with differential circuit breaker 32 A - 300 mA + surge arrester type A.
Electrical box (alternative current) for photovoltaic protection. Cabinet includes the wiring diagram. Required for each photovoltaic system. AC enclosure 5-6kW IP65 single phase 230VAC 32A differential circuit breaker 30mA typeB-APR + Surge arrester type 2.. Enclosure for installation with battery only. Plastic enclosure 12M, 246x310x148mm
Electrical box (alternative current, 3-phase) for photovoltaic protection. Cabinet includes wiring diagram. Required for each photovoltaic system. AC box 400 V AC 3-phase AC 20 to 40kW with differential circuit breaker 63 A - 300 mA + surge arrester type A.
For SOLAX inverters G4 versions, you can eliminate complex cable connections by using the MATEBOX. This box includes: - EPS BOX- Circuit breaker- Meter-Disconnector
For SOLAX inverters G4 versions, you can eliminate complex cable connections by using the MATEBOX. This box includes:EPS BOX Circuit breaker Disconnector Meter
Electrical box (alternative current 3-phase) for photovoltaic protection. Cabinet includes the wiring diagram. Required for each photovoltaic system. AC box 400 V AC 3-phase AC up to 10 kW with differential circuit breaker 16A B-Typ - 30 mA + surge arrester type A. Box for installation with inverter that manages the batteries.
Electrical box (alternative current) for photovoltaic protection. Cabinet includes the wiring diagram. Required for each photovoltaic system. AC enclosure 5-6kW IP65 single phase 230VAC 50A 30mA differential circuit breaker type B-APR + Lightning arrester type 2. Enclosure for installation with battery only. Plastic enclosure 12M, 246x310x148mm
Electrical box (alternative current 3-phase) for photovoltaic protection. Cabinet includes the wiring diagram. Required for each photovoltaic system. AC box 400 V AC 3-phase AC up to 20 kW with differential circuit breaker 32A B-Typ - 30 mA + surge arrester type A. Box for installation with inverter that manages the batteries.
